There is an XL6009 integrated switching voltage regulator on the DC-DC step-up voltage regulator board.

Up to 4A current can be flowed through the regulator.

Input voltage is between 3.5-32V.

According to the voltage applied in this range, an output voltage between 5-35V can be obtained by taking advantage of the trimpot on the card.

This very easy-to-use and high-performance voltage regulator card allows you to adjust your input voltages in many hobby and robotic projects.

Note: The input voltage must be at least 3.5V for the card to work.

There is a pin slot for the connection of input and output voltages on the regulator board.

It can be used here by soldering cables and male or female headers.

In card applications, the output voltage must always be higher than the input voltage.

The IN+ positive supply input on the card is the IN-ground, the OUT+ positive output voltage, and the OUT- is the ground output.

Features: Input Voltage: 3.5-32V Output Voltage: 5-35V
